Rider A4

Rider A4

  • Strong and lightweight alloy frame with lowered top center tube
  • Durable and lightweight V-Class Zeta MLO alloy suspension fork with mechanical lock-out
  • Mechanical Disc Brakes with Aluminum Levers
  • Shimano Tourney 8 speed rear derailleur and 3 speed front derailleur with Shimano Acera shifters
  • Cassette Skilful CS-M220 11-32T, 8 Speed
  • 26" / 27,5" / 29" wheels size

Description

The MTB grade VNC Rider A4 bike is designed with an aluminum sports frame that has the optimal balance of strength, lightness, corrosion and moisture resistance.


The central, upper profile tube is lowered and forms a smooth geometry with a narrow lumen triangle for dynamic pedaling, easy landing and jumping off the bike without the risk of injury.


Also made from aluminum is the lightweight and reliable V-Class Zeta City HLO suspension fork with hydraulic lockout for easier handling of difficult road sections on rough terrain.


High quality and powerful Logan mechanical disc brakes provide instant stopping power by gripping the wheel rotors with the slightest effort on the aluminum handlebars.


The dynamics of the bike is represented by a 24-speed transmission (3x8) and is assembled on proprietary Shimano Tourney equipment, which gives the rider a wide range of gears for riding in a wide variety of terrain. Shimano Altus monoblock shifters provide smooth and precise shifting.


The Skilful CS-M220 11-32T 8-speed cassette is efficient in operation and has an excellent gear work.


Wheels with a diameter of 27,5'' and 29'' show fast acceleration, are suitable for high-speed conditions and easy overcoming of difficult roads.


The seat tube height adjustment allows the rider to optimize the riding position for comfortable riding conditions over long distances.

Specification

Frame VNC MTB ProLite, alloy
Fork V-Class Zeta MLO, 100mm, alloy
Shifters Shimano Acera SL-M315, 3x8 speed
Front derailleur Skilful FD-M200, 3 speed
Rear derailleur Shimano Tourney RD-TX800, 8 speed
Cassette Skilful CS-M220-8, 11-32t
Crankset V-Class Zeta, 24T/34T/42T, alloy
Chain KMC Z8.3
Bottom bracket Sealed cartridge, BSA
Brakes Logan, mechanical disc brake, rotor: 160/160 mm
Brake Levers Logan, alloy
Hub (front) V-Class Sigma, disk, quick release. alloy
Hub (rear) V-Class Sigma, disk, quick release. alloy
Handlebars V-Class Delta, steel
Stem V-Class Sigma, alloy
Seatpost V-Class Sigma, alloy
Saddle V-Class MontRace
Headset VNC M2, A-Headset, semi-integrated
Rims V-Class Sigma, disc, double wall, alloy
Spokes Stainless Steel
Tires Compass MTB, 26"(27,5"/ 29")x2.30"
Pedals V-Class FP-803, ball bearings
Grips V-Class Pro MTB
Approx weights in kg 14,6
Color Black / Grey / Orange
Frame size XS6 / S7 / M7 / L9 / XL9

* We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, and materials.

Size chart

Geometry

XS6 S7 M7 L9 XL9
A bb center to top of seattube 360 410 450 470 510
B top tube parallel 537 562 584 579 593
B* top tube horizontal 541 586 610 605 620
C chainstay 424 435 435 455 455
D headtube length 110 110 110 110 110
E head angle 68,5 ° 70 ° 70 ° 71 ° 71 °
F seat angle 74,5 ° 73 ° 73 ° 73 ° 73 °
H bb offset 45 42 42 75 75
K wheelbase 1065 1083 1107 1116 1131
G seatpost diameter 30,4 30,4 30,4 30,4 30,4
