Emily AC

Emily AC


  • Strong and lightweight alloy frame with lowered top center tube
  • Rear foot brake (coaster brake) and front rim brake (V-Brake) with alloy brake levers
  • 24" wheels size

Description

The VNC Emily AC teen bike is made with an aluminum frame, which has excellent strength qualities at light weight, which is the optimal solution for mid-level bikes. The geometry of the frame is understated, has smooth lines and promotes easy landing and unobstructed jumping from the bike without the risk of injury. For additional strength, the frame profile is reinforced with a reliable tube that connects the main and seat tube.


For braking efficiency, the brake system is combined: the rear foot brake is triggered counterclockwise by the connecting cranks. The front brake is performed by a simple and reliable V-brake system, which clamps the rim of the wheel with two pads when squeezing the lever, which is placed on the handlebars of the bike.


Wheels with a diameter of 24'' inches accelerate quickly, are good in rolling and braking, which meets all the demands of riding a teenager.


Possibility of adjustment of height of a saddle and a wheel allows to pick up the most convenient position and to provide equal landing that is important at long rides.


Bright, simple, reliable - and this is not all the advantages of this bike, which can safely be called the best choice.

Specification

Frame VNC Junior Monotube Type, alloy
Fork V-Class Rigid Junior, steel
Shifters -
Front derailleur -
Rear derailleur -
Freewheel V-Class City, 16t
Crankset V-Class Zeta Kids, 40T, alloy
Chain TEC
Bottom bracket Sealed cartridge, BSA
Brakes Logan, v-brake / rear coaster brake
Brake Levers Logan, alloy
Hub (front) V-Class Delta, quick release, steel
Hub (rear) V-Class Coaster Brake, steel
Handlebars V-Class Delta, steel
Stem V-Class Sigma, alloy
Seatpost V-Class Sigma, alloy
Saddle V-Class MontRace JR
Headset VNC M2, A-Headset, semi-integrated
Rims V-Class Sigma, disc, double wall, alloy
Spokes Stainless Steel
Tires Compass MTB, 24"x1.95"
Pedals V-Class FP-803, ball bearings
Grips V-Class Revo MTB
Approx weights in kg 10,5
Color White / Purple / Pink
Frame size XXS4

* We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, and materials.

Size chart

Geometry

XXS4
A bb center to top of seattube 280
B top tube parallel 470
B* top tube horizontal 484
C chainstay 415
D headtube length 105
E head angle 71 °
F seat angle 73 °
H bb offset 25
K wheelbase 993
G seatpost diameter 31,8
