HighWay EQ

HighWay EQ


  • Foldable high-tech aluminum frame with foldable bike components such as handlebar stem and plastic pedals
  • Logan hydraulic disc brakes with alloy brake levers
  • Shimano Altus 8-speed rear derailleur with Shimano shifters
  • Cassette Shimano CS-HG31-8 11-30T, 8 Speed
  • Pre-installed durable alloy rear rack
  • 24" wheels size

Description

The VNC HighWay EQ bike is designed with a high-tech, foldable aluminum frame, which is the optimal solution in terms of strength, lightness and protection from moisture and corrosion. The innovative geometry of the frame has smooth, lowered lines, creating a clear space from the seatpost to the head tube, which provides the most comfortable pedaling, easy landing and jumping off the bike.


Today's best, durable Logan hydraulic disc brakes provide instant stopping power, allowing you to control any speed conditions. The specificity of the hydraulic brake is that the pads are triggered with the slightest effort on the brake levers, instead of a cable, a hydraulic line is connected to them.


The bike's transmission has 8 speeds (1x8) and runs on Shimano Altus proprietary equipment, the Shimano RevoShift shifter, placed on the handlebars, is responsible for gear shifting.


The 24'' wheel size is an advantage for folding bicycles, as it allows for high speeds, long roll-off and easier overcoming of difficult road sections.


The constructive seat tube height adjustment helps you find the most comfortable fit, and the folding frame, handlebar stem and plastic pedals quickly give the bike a compact shape.

Specification

Frame VNC City Folding ProLite, alloy
Fork V-Class Rigid City, alloy
Shifters Shimano SL-RS47, 1x8 speed
Front derailleur -
Rear derailleur Shimano Altus RD-M310-smart, 8 speed
Cassette Shimano CS-HG31-8, 11-30t
Crankset V-Class Sigma, 48T, alloy
Chain KMC Z8.3
Bottom bracket Sealed Cartridge
Brakes Logan, hydraulic disc brake, rotor: 160/160 mm
Brake Levers Logan, hydraulic, alloy
Hub (front) V-Class Sigma, disk, quick release, alloy
Hub (rear) V-Class Sigma, disk, quick release, alloy
Handlebar V-Class Sigma, alloy
Stem V-Class Sigma Folding, regulated, 230mm, alloy
Seatpost V-Class Sigma, alloy
Saddle V-Class CityLine
Headset VNC M3, F-Headset, semi-integrated
Rims V-Class Sigma, disk, double wall, alloy
Spokes Stainless Steel Black
Tires Compass City, 24"x1.5"
Pedals V-Class Folding, ball bearings
Grips V-Class City
Carrier V-Class City, steel
Mudguards V-Class City, plastic
Approx weights in kg 13,4
Color Black / Grey / Blue
Frame size M4

* We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, and materials.

Size chart

Geometry

S2 M4 M6
A bb center to top of seattube 330 380 -
B top tube parallel - - -
B* top tube horizontal - - -
C chainstay 389 440 -
D headtube length 110 110 -
E head angle 73 ° 73 ° -
F seat angle - - -
H bb offset 20 20 -
K wheelbase 989 1069 -
G seatpost diameter 40,8 40,8 -
