Wave AC

Wave AC

  • Strong and lightweight alloy frame with lowered top center tube
  • Rear foot brake (coaster brake) and front rim brake (V-Brake) with alloy brake levers
  • 24" wheels size

Description

Children's bicycle VNC Wave AC, the production of which took into account all the features of children's riding, making it reliable, durable and resistant to deformation after falls, has a low profile geometry, which is very important when planting young children.


The frame is made of the strongest of all known types of aluminum and perfectly copes with any type of load.


Elegant and coordinated brake system work is shown in fact by the combined rear coaster brake and front v-brake with a handle on the steering wheel, which clamps the rims of the wheel.


Wheels will be appreciated by every child, thanks to the optimal, small size, they have the ability to accelerate very quickly.


Another advantage of this model is the adjustment of the steering wheel and seat tube to a comfortable and not harmful to the posture height.


For a comfortable ride, the bike can be supplemented with a basket, connecting rods, as well as training wheels. All parts are strong and will last a long time with proper care.

Specification

Frame VNC Junior Wave Type, alloy
Fork V-Class Rigid Junior, steel
Shifters -
Front derailleur -
Rear derailleur -
Freewheel V-Class City, 16t
Crankset V-Class Zeta Kids, 40T, alloy
Chain TEC
Bottom bracket Sealed cartridge, BSA
Brakes Logan, v-brake / rear coaster brake
Brake Levers Logan, alloy
Hub (front) V-Class Delta, quick release, steel
Hub (rear) V-Class Coaster Brake, steel
Handlebars V-Class Delta, steel
Stem V-Class Sigma, alloy
Seatpost V-Class Sigma, alloy
Saddle V-Class Comfort Kids
Headset VNC M2, A-Headset, semi-integrated
Rims V-Class Sigma, disc, double wall, alloy
Spokes Stainless Steel
Tires Compass MTB, 16"(18"/20")x2.10"
Pedals V-Class FP-803, ball bearings
Grips V-Class Revo MTB
Approx weights in kg 8,1
Color Black / White / Red
Frame size 16, 18, 20

* We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, and materials.

Size chart

Geometry

XXS4
A bb center to top of seattube 280
B top tube parallel 470
B* top tube horizontal 484
C chainstay 415
D headtube length 105
E head angle 71 °
F seat angle 73 °
H bb offset 25
K wheelbase 993
G seatpost diameter 31,8
